    KLS2-219 PUSH WIRE connector for 2.5mm² WAGO273

    COMPACT Splicing Connector,For all types of conductors 2.5 mm²

    Features:
    1. wago 273 type perfect analogue

    WAGO  P/N                  KLS P/N
    273-112              KLS2-219-02P-1
    273-104              KLS2-219-03P-1
    273-102              KLS2-219-04P-1
    273-105              KLS2-219-05P-1

    Electrical data
    Rated voltage (II / 2)                      400 V (IEC) /  600V(UL)
    Rated impulse voltage (II / 2)           4 kV
    Rated current                                24 A
    Legend (ratings)                            II / 2
    Overvoltage category                     II
    Pollution degree                             2

    Connection data
    Connection technology                   CAGE CLAMP®
    Connectable conductor materials      Copper
    Nominal cross section                    1~2.5 mm² /18~12AWG
    Strip length                                 10~13 mm / 0.45 Inch
    Total number of connection points   2,3,4,5
    Total number of potentials             1
    Type of wiring                              Side-entry wiring

    Material Data
    Color                                          Gray
    Flammability class per                    UL94 V2

    Environmental Requirements
    Surrounding air (operating) temperature     105 °C
