    KLS12-RJ45C-8P RJ45 Modular Plug

    RJ45 Modular Plug

    MATERIAL
    1.Housing :Polycarbonate(pc) UL 94V-0 or UL 94V-2
    2.Contact :Phosphor Bronze, Hard Gold plated over nickel
    3.Shielding:0.25mm Thickness Copper Alloy With Tin plated
    4.Gold plating:3u inch,6u inch,15u inch,30u inch,50u inch

    ELECTRICAL
    1.Current Rating:1.5 Amps
    2.Voltage Rating:125 Volts AC
    3.Insulation Resistance:100 Megohms Min.
    4.Contact Resistance:39 Millmhos Max.
    5.Withstanding Voltage:1000VAC RMS 50Hz or 60Hz 1 Min.

    MECHANICAL
    CABLE TO PLUG TENSILE STRENGTH:7.7Kg MINI
    DURABILITY:750MATING CYCLES MINI
    WORKING TEMPERATURE:-40°C ~60°C
