    KLS2-DGKR-5.08 PluggableTerminal Black 5.08mm

    Material
    Screw:         M3, Steel,Zn plated
    Cage:           Brass, Nickel plated
    Pin header:  Brass, Tin plated
    Housing:      PA66, UL94V-0

    Electrical
    Rated voltage:  300V
    Rated current:  15A
    Wire range:      28~14AWG  2.5mm²
    Contact Resistance: 20 m Ω
    Insulation resistance:  500MΩ/DC500V
    Withstand voltage:      AC2000V / 1 min

    Mechanical
    Temp. Range:     -40 ° C ~ + 105 ° C
    Torque:             0.5 N.m (4.43 Lb. in)
    Strip length:     7~8 mm
