    KLS2-THR301-5.00 Through hole reflow 5.00mm pitch

    Material
    Screw:        M2.5, Steel,Zn plated
    Shrapnel:     stainless steel
    Pin header:   Brass, Tin plated
    Housing:       LCP, UL94V-0

    Electrical
    Rated voltage:  300V
    Rated current:  16A
    Wire range:      22~14AWG  1.5mm²
    Contact Resistance: 20 m Ω
    Insulation resistance:  1MΩ
    Withstand voltage:      AC1600V / 1 min

    Mechanical
    Temp. Range:   -40 ° C ~ + 115 ° C
    Soldering:         265 ° C   5Sec.  Max.
    Torque:            0.4 N.m (3.5Lb. in)
    Strip length:     5~6 mm
