KLS8-SHM02 SHUR PLUG Male Terminal
P/N | Material | Plating | Dimension(mm) | Wire Range | Q'TY | REMARKS | ||||||||
W | E | L | T | H1 | WS | H2 | IS | (AWG) | REEL | |||||
L-KLS8-SHM020401 | Brass | Tin | 4.56 | 11.8 | 22.2 | 0.40 | 3.90 | 3.30 | 5.10 | 4.80 | 14~18 | 5000 | L-KLS8-SHF020401 L-KLS8-SHF030401 |
