KLS1-108N 2.0mm Pitch ZIF Socket Connector
5.0
Place of Origin:
China
Payment:
L/C, D/A, D/P, T/T
MOQ:
1000 PCS
Model:
KLS1-108N
Delivery Time:
10 days
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
KLS1-108N 2.0mm Pitch ZIF Socket Connector
Material:
Housing: 30% Glass filled PBT UL 94V-0
Contacts: Phosphor Bronze
Plating: Gold plated: 3u" over 50u" nickel
Tin plated: 100u" over 50u" nickel
Electrical Characteristics:
Current rating: 1AMP.
Insulator resistence: 5000MΩ min, at DC 500V
Contact resistence: 20mΩ max, at DC 100mA
Operating Temperature: -55°C~+105°C
Features:
Lever actuated zero insertion force mechanism
Socket easily disassembles for repair ability
